Dante 2 Channel Analog Audio Encoder Decoder with POE
Dante Audio Intergration Transmitter and Receiver up to 100meter via Cat6/6a
| Weight | 400 g |
|---|---|
| Dimensions | 12 × 4.7 × 2.6 cm |
| Video Network Bandwidth | 100M |
| Audio Formats | PCM 2.0 44.1kHz/48kHz/96kHz up to 24bit |
| Transmission Distance | 100m (CAT6/6A) |
| Control Method | Dante Controller |
Detailes About Dante 2 Channel Analog Audio Encoder Decoder with POE
Encoder Introduction
This Dante 2CH Analog Audio Encoder is an audio transmitter based on the Dante Ultimo solution. It supports balanced/unbalanced audio input and 3- level gain adjustment. It encodes audio signals, and then transmits the audio to the receiving end through network (Dante). It supports POE function.
Encoder Features
☆ Analog audio input supports balanced/unbalanced audio input (unbalanced access to “+” and “GND”)
☆ Audio sampling rate supports 44.1kHz, 48kHz and 96kHz (24bit)
☆ Dante solution supports AES67 RTP audio transmission
☆ Audio input supports 3-level gain adjustment： +18dBu, 0dBu (default) and -10dBV
☆ Support DC 12V power supply and POE function (IEEE802.3af Class 0)
Decoder Introduction
This Dante 2CH Analog Audio Decoder is an audio receiver based on the Dante Ultimo solution. It supports balanced/unbalanced audio output and 3- level gain adjustment. It receives audio signals from the transmitting end through network (Dante), then decodes and outputs the audio as analog audio. It supports POE function.
Decoder Features:
☆ Analog audio output supports balanced/unbalanced audio output (unbalanced access to “+” and “GND”)
☆ Audio sampling rate supports 44.1kHz, 48kHz and 96kHz (24bit)
☆ Dante solution supports AES67 RTP audio transmission
☆ Audio output supports 3-level gain adjustment：+18dBu, 0dBu (default) and -10dBV
☆ Support DC 12V power supply and POE function (IEEE802.3af Class 0)
