What is EDID ? EDID pass-through refers to a play-back device that can read the display device’s information,such as resolution, factory model, date of manufacturer, and so on. The Benefit of EDID pass-through is the player can read the resolution of the display device directly so that the video signals that the display device can accept can be output in the best effect. TCL in the figure means TCL TV, TOS is short for TOSHIBA, that is, this product can reach the EDID information of the display device perfectly. The product supports EDID unvarnished transmission. The EDID information of the display device will be automatically read and supplied to the signal source after powering on or replacing the display device, This will result in better device compatibility. What is EDID Mix？ As a TV with a different model and resolution, it reads the TV’s resolution ratio before the splitter/switcher/matrix/extender transmits data to the TV, automatically chooses a suitable resolution ratio, then sends data out.

There are three responses to a HDMI Extender : Yes, No and WOW ! WOW is the one we aim for. Some new customers inquiry for the HDMI over Ethernet extender and even they didn’t know what’s the use of hdmi extenders? How they works ? Does they work at our office? This article will explain you these questions. What’s the use of HDMI extenders ? HDMI extenders are used for extending long distance (60meter/100meter/120meter ) between a high definition television (monitors ) and a digital sending device (such DVD player, laptop/computer,media-box, set-top box,PS3/4) , transmit the video signal by One single Cat5e/6 cable. You connect a video source to the transmitter, a display to the receiver, and link the two with a Cat5e/6 cable. These cables are much cheaper than HDMI cables, and can run longer distances. How the HDMI signal extender solve your problem ? It can solve the problems caused by signal limitations and allow you to enjoy High definition pictures to the longest distance. It enables multiple devices which have HDMI port , no matter where you are, simply booster your HD signal everywhere around your house/ office/ shop/ bars/ school, etc. How they benefit you and how they works ? For example, before you haven’t bought the HDMI extenders , if you want to watch a Blu-ray DVD player on a television in another room, maybe you are thinking of buying a long HDMI cable which the signal may be very bad and higher cost,

Some customers want to take their IP cameras to monitors across 150m/200m which installed on their church，stores, hotel ,supermarket,school,office and home. Meanwhile, customers want to display a live view of their security cameras on multiple TVs in different rooms. This IP Extender/KVM Extender is the best solution for IP Camera DVRs booster long-distance video signals to HDTV/Monitors. It can be used in offices, retail stores, hotels, restaurants, show stages, schools, supermarkets, hospitals, banks, etc.    It is the most economic system to extend the long distances from your IP Camera to your Monitor. The extender connects with a security camera DVR or network video recorder up to 393ft/492ft / 574ft away from the monitor / TV displays. It converter the HDMI video signal from the DVR or NVR, then run through a single Cat6 cable in the wall to transmit the 4K 30HZ / 4K 60HZ video signal to TVs. Notes: To ensure the video signal quality, please use better quality solid copper Cat6 cable. If you use cheaper CCA or CCS wire which will result in bad video quality and signal loss. The HDMI IP Extender can be installed in different ways including direct one to one connection, one to many connections, and many to many connections. Direct point to point connection If your IP camera have HDMI port,like below one, you can connect with the extender directly. Using DVR and Router to extend long distance via HDMI Extender with Network IP Cameras If your IP camera didn’t have

Audio Video signals run to a gazebo, a garage, a treehouse, downstairs, upstairs, pass through the wall ( click in wall wallplate extender).you can interchange whatever source you have, cable box blu-ray player, SONY, PANASONIC, PIONEER, Samsung, Output compatible with different brands of HDTVs. Below points explain you some professional function for better understanding and operation. EDID and Zero Video Latency EDID is the AV industry standard for your output display (your screen, TV, or projector) to communicate with your AV source device (for example your Sky Box or Blue-Ray player), sending detailed information on the display and sources capabilities (such as the size, format, and resolution of the screen). Two steps to reset the EDID copy function? 1.Please connect the transmitter with the source and receiver with the display.2.Press the EDID button in which the button is on the transmitter side for 1-2 seconds. Your status lights will change from red to green, then back to red. This indicates a successful EDID copy. How long it can extend and which cable you can use ? NOTE: We recommend using direct HDMI to HDMI connection,to avoid using signal converters or adapters at all costs. CAT 5 cable is NOT recommended because of the different quality levels in the market and solid (Aluminium) COPPER Cat 6 cable will display the best signal quality. IR ( one-way direction IR control ) Plug the infrared sensor into your receiver and your transmitter, you can send IR signals more than 200ft length (added the cable

This article will show you how to connec your HDMI extender.Hope it will solve your problems.

Detail introduction of HDMI over ethernet & HDMI Extender
