HDMI 2X1 Video Capture Card Switcher with Audio

4K USB 3.0 Video Capture Card Dongle 1080P for OBS Capturing Gaming Live



Additional information

Weight 125 g
Dimensions 11.3 × 5.6 × 1.8 cm
Resolution

4K, 60Hz

Support

mainstream equipment like Phone, PS3,PS4,XBOX,Set-top box,Camera,Projector and more.

Compatible

Windows, Linux, Mac OSX operating systems.

USB Port

USB 3.0 USB 2.0

Audio

48KHz PCM

Markets

Residential

Detailes About HDMI 2X1 Video Capture Card Switcher with Audio

USB 3.0 Capture HDMI  2×1 with Loop HDMI 4K60HZ  and Mic Audio

USB 3.0 Game Capture Card 4K  60Hz HDR RGB 4:4:4

HDMI to USB3.0 Video Capture Dongle, it is easy to carry, has superior performance, superior compatibility, simple installation, and many other features.

It can capture one HDMI 4Kp60 input ,output HDMI 4Kp60 and USB 1080p60 signals.

The HDMI video capture meets UVC and UAC standard, without having to install drivers and settings, the real PnP, easy to use.

Features:

It doesn’t need to install a driver, and it is truly PnP.

It is compatible with Windows, Linux, OS X operating systems

USB3.0, 300-350MB/s throughput and it is compatible with USB 2.0

The process of video and audio is done by the dongle and will not occupy the CPU.

It can capture one single channel HD HDMI video signal.

It can automatically detect the input video formats and it will adjust to the set output size and frame rate automatically.

Support HDMI 2.0b and HDCP 2.2.

Support MIC input and audio output.

Support HDMI loop output 4Kp60.

Package:

USB3.0 Capture HDMI 4Kp60 Box——1Pcs

IR Remote-control unit——1Pcs

USB3.0 to Type C Cable—–1Pcs

USB 3.0 Cable——-1Pcs

HDMI Cable————1Pcs

USB Power Cable—–1Pcs

User manual——–1pcs

Specification :

Host Interface USB3.0 ,*480MB/s,USB2.0, *40MB/s
HDMI Input & Output

Formats

480i,480p,576i,576p,720p,

1080i,1080P,4Kp30,4Kp60

USB3.0 Output Formats 640×480/720×480/720×576/768×576/800×600/

1024×768/1280×720/1280×800/1280×960/1280×1024/1368×768/

1440×900/1600×1200/1680×1050/1920×1080/

1920×1200/640×360/856×480/960×540/1024×576

Frame Rate: 30/40/48/50/59.94/60 fps
Size: 113*56*18 (mm)
Weight: 125g
Power Consumption <=2.5w
Working Temperature 0-50 degree C
Storage Temperature -20-70 degree C
Storage Humidity 5%-90%

How to use OBS to record Video ?

Step 1: Click +  Choose: Video Capture Device

Step 2: Create a new name

Step 3: Device  Choose “USB3.0 HD Video Capture”

Step 4 :Resolution /FPS Type : Choose “Custom”

Step 5 : Resolution : Choose “1920×1080”

Notice :

Step 6: Audio Output Mode: Choose “Output desktop audio (direct Sound)”

Step 7: ✔ USB custom audio device

Step 8: Audio Device: Choose “USB 3.0 HD Audio Capture”

Step 9: Click: “Start Recording”
