AES67 2 Channel Audio Adapter,Audio Line Input/outpu ,USB-C I/O Adapter,POE
AES67 2CH Dante Audio Adapter,Line input/output Adapter, XLR input/output Audio AES67 Adapter, POE power
| Weight | 200 g |
|---|---|
| Dimensions | 13 × 11 × 3 cm |
| Interface | Line in /out, XLR In/out, USB-C I/O Port |
| Frequency Response | 20Hz-20kHz |
| Signal-to-noise ratio | >100dB |
| THD+N | < 0.01%@4 dBu |
| Background noise | -90dB |
| Power Consumption | 2W |
| Ethernet connection | 100BASE-TX(Support PoE) |
| USB specification level | ≥ USB 2.0 |
| Configurable dante audio delay | 1,2,or 5 milliseconds |
Detailes About AES67 2 Channel Audio Adapter,Audio Line Input/outpu ,USB-C I/O Adapter,POE
Two-channel AES67 Audio Adapter,Support Dante Controller or AES67 Controller ,POE or USB-C power
Supports balanced and unbalanced analog audio input/output
Supports input equalization and 48V phantom power
Configurable via Dante Controller or AES67 Controller
PoE or USB-C local power supply
Compliant with IEEE 802.3af Class 0 PoE standard, can be powered by any PoE switch
2Ch AES67 USB-C Audio adapter with POE
2×2 Channel AES67 → USB-C Bidirectional Audio Converter (Plastic Housing)
Compliant with USB Audio Device Class V2.0
Configurable via Dante Controller or AES67 Controller
PoE Power (IEEE 802.3af Class 0) or USB-C Local Power Supply
2Ch AES67 XLR Audio Adapter with POE
AES67 Dual-Channel XLR Input/Output Adapter
Supports analog XLR balanced or unbalanced audio input/output
Supports input sensitivity adjustment and 48V phantom power
Supports configuration via Dante Controller or AES67 Controller
PoE power supply or USB-C local power supply
Compliant with IEEE 802.3af Class 0 PoE standard, can be powered by any PoE switch
Easy Control. 100% Dante Software compatible.
Take command with Dante Controller, easily manage and adjust settings. With true plug-and-play functionality, your installation is up and running in no time, with no hassle.
Interconverts between two-channel USB audio and Dante® 2CH digital audio
APPLICATION SCENARIO
It is suitable for meeting room, exhibition hall, small activities, classroom interaction and other occasions.
