2020 New 4K HDMI Extender By Single Cat 6/7 with IR Cascade connection 1080P 3D
| Weight | 290 g |
|---|---|
| Dimensions | 9.4 × 9.4 × 2.8 cm |
| HDMI Version | 1.4 |
| Resolution | 480P/720P/1080P/4K@24Hz/4K@30Hz Supports 3D etc. |
| HDCP | HDCP1.4 |
| Markets | Retail, Residential, Venues, Government, Hospitality, Corporate, Education |
| Cat6 Cable Perfomance | 70Meter, 230 Feet HD Transmission |
Features
Extend a full 4K video signal up to 70m (230 feet) using 1 CAT6 cable.
Following Standard IEEE-568B wiring method.
Support Point to Point connection and One to Many connections.
Description
HDMI extender is your low-cost solution when an HDMI signal needs to be extended up to 230 Feet.
SPECIFICATIONS:
|
Model name
|
4K HDMI Extender By CAT
|
|
HDMI resolution
|
480P/720P/1080P/4K@24Hz/4K@30Hz Supports 3D etc.
|
|
HDMI Audio format
|
AC-3/DTS/DTS-HD/PCM
|
|
HDMI Max bandwidth
|
300MHz Max
|
|
HDMI Max baud rate
|
9Gbps Max
|
|
Network cable interface
|
Standard IEEE-568B wiring method
|
|
Transmission
distance |
≤70m (Cat 6e) If need longer distance, please use the cascade link.
|
|
IR Carrier frequency
|
30~50KHz
|
|
POC features
|
support
|
|
Output HDMI cable distance
|
2160P/AWG 26 ≤3m
1080P/AWG 26 ≤8m |
|
Power adapter
specification |
AC 100~240V/DC 5V/1.5A
|
|
Max working current
|
450mA
|
|
Size
|
93.5×93.8×28(mm)
|
|
Weight
|
TX≈145g/RX≈145g
|
|
Accessories
|
Manual x1, Power Adaptor x1、IR Transmitter cable x1、 Receiver cable x1
|
Function Advantage: Each RX at the cascade link have separate Scaler Down function, TX Loop Out port do not support Scaler Down function,
