Overview

 This HDMI Extender can extend HDMI signal up to 3300 feet/1000 meters (over single-mode fiber cable) or 1000 feet/300 meters optional (over multi-mode fiber cable).

Video resolution is up to 4K2K@60Hz 4:4:4. Transmitter supports loop output, audio embeding and EDID managment function.

Receiver supports audio extracting function.

In addition, the extender supports bidirectional IR control and RS-232 signal pass-through.

It can allow you to easily control the display device on the signal source side or control the signal source device on the display side when using this extender.

(Our current shipping extender includes single-model fiber inside,so it supports single mode fiber cable,

if there is multi-mode fiber inside the extender, it supports multi-mode fiber cable )

1) HDMI 2.0b, HDCP 2.2 and DVI 1.0 compliant

2) Support 18Gbps video bandwidth

3) Video resolution up to 4k2k@50/60Hz 4:4:4

4) HDMI audio formats: LPCM2/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True

HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio,DSD

5) Support 3D and HDR format video, does not support CEC control

6) Transmission distance up to 3300 feet/1000 meters (over single-mode

fiber cable) or 1000 feet/300 meters (over multi-mode fiber cable) (50/ 125um/OM3) (optional)

7) Support bidirectional IR control, RS-232 pass-through and EDID management for simple and convenient control

8)Transmitter supports loop output (sharing local HD video and audio) and audio embeding function

9) Receiver supports audio extracting output function

10) Compact design for easy and flexible installation
