4K30Hz 4×1 Seamless Switch Multiview with RS232,Audio Extractor L/R Analog Audio Output 8 Display Modes
4K30hz Presentation System 4×1 seamless switcher with multi viewer , RS232 Control,Audio Out,No black screen while switching,No tearing screen.
| Weight | 300 g |
|---|---|
| Dimensions | 17.6 × 6.8 × 1.8 cm |
| HDMI Version | HDMI 1.4b |
| Video Resolution | Input: Up to 4K@30Hz |
| HDCP | 1.4 |
| IR | 5Vp-p,Fixed Frequency 38KHz |
| Multiview modes | SINGLE, PIP, PBP (1), PBP (2), Triple (1),Triple (2), Quad (1), Quad (2) |
| Audio Formats | HDMI IN/OUT: |
| Color space | RGB_4:4:4, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0 |
| ESD Protection | IEC 61000-4-2: |
Detailes About 4K30Hz 4×1 Seamless Switch Multiview with RS232,Audio Extractor L/R Analog Audio Output 8 Display Modes
4K30 4X1 Seamless Switcher with Multiviewer
Introduction
The high performance 4×1 quad multi-viewer supports four routes HDMI high definition input contents to be displayed on one HDMI screen. It supports audio output selected from different input sources independently. 8 multi-view display modes are also supported. Output resolutions can be adjusted up to 4K30Hz. The product can be controlled via front panel buttons, IR remote and RS-232 control.
☆ HDCP 1.4 compliant
☆ Support 10.2Gbps video bandwidth
☆ Input and output resolution is up to 4K@30Hz, as specified in HDMI 1.4b
☆ Support auto switching and manual switching
☆ Seamless switching between inputs and combined multiple images on single UHD monitor in multi-view display mode
☆ Seamless switching in single-view display mode
☆ Support 8 display modes: SINGLE, PIP, PBP (1), PBP (2), Triple (1), Triple (2), Quad (1), Quad (2)
☆ Support LPCM, DD, DD+, DTS audio channel
☆ Support audio de-embedding via the analog audio port
☆ Support independent audio selection
☆ Support OSD display in multi-view display mode
☆ Control via front panel button, IR remote and RS-232 commands
☆ Advanced EDID management
☆ Compact design for easy and flexible installation
Package
① 1× 4K30 HDMI 4×1 Quad Multi-viewer & Seamless Switcher
② 1× 5V/1A Multinational Power Supply
③ 1× IR Remote
④ 1× IR Receiver Cable (1.5m)
⑤ 2× Mounting Ear
⑥ 4× Machine Screw (KM3*4)
⑦ 1× 3pin-3.81mm Phoenix Connector (Male)
⑧ 1× User Manual
POS: Press to switch the position of PIP view: top left, bottom left, top right, bottom right.
SIZE: Press to switch the size of PIP view: large, middle, small.
Display Mode: Press to select the multi-view modes as follow:
16:9: Press to switch the aspect ratio between full-screen and 16:9.
