HDMI 2.1 48Gbps 8K60Hz HDR HDMI Switch 2×1 1×2 2×2 Switch Splitter with Remote Controller,CEC
8K 2×1 1×2 HDMI Switch Splitter 4K@120Hz 8K@60Hz HDMI 2.1 HDMI Switcher HDR UHD VRR for PS5 XBOX Series X 8K TV
| Weight | 188 g |
|---|---|
| Dimensions | 11 × 7.5 × 2 cm |
| HDMI Version | 2.1 48Gbps |
| Resolution | Up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit |
| HDCP | HDCP 2.3 |
| Audio Format Support | LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res,DTS-HD Master Audio, DTS:X, DSD |
| HDMI Input Port | 2 Ports |
| Markets | Residential |
| ESD Protection | IEC 61000-4-2: ±8kV (Air-gap discharge), ±4kV (Contact discharge) |
| Color Space | RGB_4:4:4, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0 |
| Video Bandwidth | 48Gbps FRL and 18Gbps TMDS |
| Control | Front Panel button and IR remote controller, with certified power supply |
Detailes About HDMI 2.1 48Gbps 8K60Hz HDR HDMI Switch 2×1 1×2 2×2 Switch Splitter with Remote Controller,CEC
8K60 Switch Splitter 2×1 1×2
Feature：
Compliant with HDCP 2.3 standard, 48Gbps video bandwidth
Video resolution: 8K@60Hz 4:2:0, 8K@30Hz 4:4:4, 4K@120Hz 4:4:4
2-in/2-out switcher, supports dual output
HDR, HDR10, HDR10+, Dolby Vision, HLG pass-through
Audio formats: LPCM, Dolby Digital / Plus / EX, Dolby TrueHD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
Supports EDID management: STD and TV
Controllable via front panel buttons and infrared remote control
Supports automatic and manual switching
Video resolution scaling: 8K → 4K, 8K/4K → 1080p
Supports CEC (only on HDMI™ Output 1)
Compact design for flexible installation
