HD Conference Camera/PTZ Camera with USB 3.0 Auto Framing & Presenter Tracking

4K HD Communication Camera ,Full HD, High-Performance 4K 20x Zoom, All Interfaces, 4KP30/25

Additional information

Weight 2500 g
Dimensions 15 × 17.5 × 17 cm
HDMI Version

4K30

Resolution

3840×2160P30/25, 1080P60/50/30/25 , 1080I/60/50, 720P60/50

Digital Zoom

20x Optical Zoom,12x Digital Zoom

Minimum Illumination

Supports ultra-low illumination: 0.1Lux@F1.6 (color), 0.01Lux@F1.6 (black and white)

Sensor

1/2.5-inch high-quality CMOS sensor, 8.51 million pixels

Interface

3G-SDI, HDMI ,Line In, Network,USB3.0,USB2.0,RS32/RS485

Detailes About HD Conference Camera/PTZ Camera with USB 3.0 Auto Framing & Presenter Tracking

Overview

This is a UHD 4K conference camera designed for use in the fields of business, education, and remote medical applications. It features multiple optical zoom options and 4K resolution, combined with superior color reproduction, allowing the camera to capture stunning on-site visuals. It is suitable for various settings such as corporate meeting rooms, classrooms, training centers, and medical facilities, enabling high-quality color video imaging.

With advanced control algorithms, this camera provides precise, smooth, and quiet PTZ (Pan-Tilt-Zoom) control. The wide-angle lens of the camera effortlessly covers all individuals in the indoor space during video conferences. With 255 presets, it allows for easy and rapid repositioning for clear images without causing any disruptions to the speakers or audience.

For convenient control and viewing, it can automatically receive VISCA commands and PELCO-P/D protocol commands.

hd conference camera/ptz camera with usb 3.0 auto framing & presenter tracking hd conference camera/ptz camera with usb 3.0 auto framing & presenter tracking

KEY FEATURES

– Precise, smooth, and quiet PTZ control with advanced control algorithms

The camera features precise motor drive and smooth, stable movements, allowing it to accurately and rapidly move to specified positions for wide-angle shots.

– True 4K Ultra HD image

 Utilizing a high-quality “Exmor R” CMOS sensor with 8.51 million effective pixels and a 1/2.5-inch size, it achieves a superior resolution of 3840×2160, delivering high-definition images while maintaining smoothness.

– Low noise with high signal-to-noise ratio

The camera incorporates 2D and motion estimation-based 3D noise reduction algorithms and a new-generation low-noise sensor, effectively reducing noise in the images.

– 20x optical zoom with a 58-degree wide-angle view and 12x digital zoom

The camera offers a versatile zooming capability with 20x optical and 12x digital zoom, providing a wide field of view.

– 4KP30 Ultra HD HDMI video output

Supports various high-definition video formats, including 4KP30/25, 1080P60/50/30/25, 720P60/50, etc.

– 4KP30 Ultra HD USB3.0 video output

Offers multiple high-definition video formats, such as 4KP30/25, 1080P30/25, 720P30/25, etc.

– 4K Ultra HD network video output

Provides support for different high-definition video formats, including 4K, 1080P30/25, 720P30/25, etc.

– 3G-SDI HD output

Supports various high-definition video formats, such as 1080P60/50/30/25, 720P60/50, etc.

– 255 position presets

Allows for pre-setting 255 positions through a serial interface, including horizontal, vertical, and zoom settings, which can be retained even when the camera is powered off.

– AI automatic tracking function

Equipped with a high-speed processor and exclusive advanced image processing and analysis algorithms, users can choose real-time tracking or area tracking based on the usage environment.

– Multi-functional remote control

The camera comes with a user-friendly remote control, allowing basic settings and control of pan, tilt, and zoom, as well as menu adjustments for camera parameters.

– OSD menu in both Chinese and English

The camera features a comprehensive OSD menu, and users can control it using the remote control in both Chinese and English.


Application Scenarios

Conference systems, remote medical, remote education, etc.

hd conference camera/ptz camera with usb 3.0 auto framing & presenter tracking

Product Parameter

Camera
Signal System 3840×2160P30/25, 1080P60/50/30/25 , 1080I/60/50, 720P60/50
Sensor 1/2.5-inch high-quality CMOS sensor, 8.51 million pixels
Scanning Method Progressive Scan
Digital Zoom 20x Optical Zoom,12x Digital Zoom
Minimum Illumination Supports ultra-low illumination: 0.1Lux@F1.6 (color), 0.01Lux@F1.6 (black and white)
Shutter 1/30s ~ 1/10000s
White Balance Auto, Indoor, Outdoor, Manual
Backlight Compensation Supported
DNR 2D&3D
Signal-to-Noise Ratio ≥52dB
Horizontal Field of View 20X:58°(wide)~2.9°(tele)
Focal length f=5.5~110mm
Horizontal Rotation Range ±170º
Vertical Rotation Range -30° ~ +90°
Horizontal Rotation Speed Range 1 º/s ~ 100 º/s
Vertical Rotation Speed Range 1 º/s ~ 60 º/s
Horizontal and Vertical Flip Supported
Number of Preset Positions 255
Preset Position Accuracy ±0.1°
Input/Output Interfaces
HD Video Interface HDMI2.0 Supports up to 4KP30
USB3.0 Supports USB 3.0 video output, with a maximum resolution of 4KP30
3G-SDI 1080P60/50/30/25、720P60/50
Network Port Encoding: H.265/H.264/MJPEG Network Protocols: IPv4, TCP, UDP, HTTP, NTP, DNS, DHCP, ARP, RTSP, RTP, RTCP, RTMP, NDI, ONVIF, VISCA OVER IP
Communication Interfaces 1* RS-232 IN, maximum distance: 30 meters, supporting VISCA/Pelco-D/Pelco-P protocols

1* RS-422, maximum distance: 1200 meters, supporting VISCA/Pelco-D/Pelco-P protocols

Power Interface JEITA Type (DC IN 12V) HEC3800
General Specifications
Input Voltage AC110V-AC220V to DC12V/1.5A
Input Current DC12V(DC11.5-DC12.5V)
Operating Temperature 0℃ to +45℃
Storage Temperature -10℃ to +60℃
Power Consumption 12W(max)
Camera Base Size Refer to “Installation Dimension Diagram”
Package Dimensions 355mmX270mmX255mm
Weight (Net Weight)) 2KG(1.2KG)
