4K60Hz 16×16 HDMI Matrix Switcher With SPDIF Audio AV Matrix YUV 4:4:4
4K60Hz 16×16 HDMI 2.0 Matrix
| Weight | 5500 g |
|---|---|
| Dimensions | 44 × 31 × 7 cm |
| HDMI Version | HDMI2.0 4K60Hz |
| Matrix mode | 16×16 switching |
| HDCP | HDCP2.2/1.4 |
| Control methods | Panel Button with LCD, IR Remote control, RS232 Control, TCP/IP Control |
| Video Format Supported | 4K@60Hz,YUV4:4:4 8bit |
| Audio format Supported | LPCM up to 7.1, Db Atmos and DTS-X Atmos |
| Audio | 16 x Analog & 16 x SPDIF Audio |
Detailes About 4K60Hz 16×16 HDMI Matrix Switcher With SPDIF Audio AV Matrix YUV 4:4:4
4K60Hz 16×16 HDMI Matrix
HDMI 2.0 16*16 Matrix with audio matrix supports 4K@60Hz 4:4:4 and 4K downscaler to 1080P. It’s under 1.5U compact in size for easy plug & play installation. Matrix can be controlled via the front panel, IR, RS-232, Telnet and Web GUI to meet every kind of testing environment and made people to use it easily.
Features
1. 16 x HDMI 2.0 input & 16 x HDMI 2.0 output
2. HDMI 2.0 version support 4K@60Hz YUV4:4:4, 18Gbps, Deep color 8bit
3. HDCP 2.2/1.4 compliant (follow input)
4. Supports Dolby Vision, HDR10, HLG
5. Supports LPCM up to 7.1, Dolby Atmos and DTS-X Atmos, 192KHz
6. Supports 16 x Analog & 16 x SPDIF Audio Matrix
7. Supports Analog Audio Volume control from level 1 ~ 10
8. Supports Panel Button with LCD, IR Remote control, RS232 Control, TCP/IP Control
9. Supports 4K downscale to 1080p (Only for outputs)
10. Supports smart EDID management
11. Supports FW updating through RS-232 port
Specificaiton:
| Input ports | 16x HDMI |
| Output ports | 16x HDMI |
|
Audio
|
16 x Analog & 16 x SPDIF Audio
|
|
Video Format Supported
|
4K@60Hz,YUV4:4:4 8bit
4k@30Hz/1080P/1080i/720P/576P/480P/576i/480i
|
| Audio format Supported |
LPCM up to 7.1, Db Atmos and DTS-X Atmos
|
| Control methods | Panel Button with LCD, IR Remote control, RS232 Control, TCP/IP Control |
| HDCP compliant | HDCP 2.2/1.4 |
|
Output Video
|
HDMI 2.0 Version |
| Bandwidth | 18Gbps |
| Power consumption |
80watts (Max.)
|
| Unit size (L*W*H) |
L438xW310xH66 mm
|
| Weight |
5.38 KG
|
Interface
Accessories
1) 1x Main Unit (HDMI Matrix)
2) 1x DC 24V/4A power adapter
3) 1x Remote control
4) 1x IR Receiver cable
5) User manual & Command list ( Download in WEB)
6) 1x 3Pin Phoenix terminal plug
7) 1.5U rack design metal case with 2 mounting ear
8) 1x USB2.0 to RS232 upgrade cable
