4K 9×9 Seamless HDMI Matrix 3×3 Video Wall Processor Multiviewer Big Screen Display

4K30Hz 9×9 Enjoy large screen HDMI 1.4 Seamless Matrix, 180°rotation,28 Videowall display modes



Additional information

Weight 4000 g
Dimensions 43 × 22 × 5 cm
HDMI Version

hdmi 1.4 4K30Hz

Matrix mode

9 x 9 seamless switching

HDCP

1.4

Video wall mode

28 video wall modes

RS232 Control

Support

TCP/IP Control

Support

Multi-viewer mode

multiple multi-viewer modes

Detailes About 4K 9×9 Seamless HDMI Matrix 3×3 Video Wall Processor Multiviewer Big Screen Display

4K30Hz 9×9 Seamless Matrix+3×3 Video Wall Processor+9×1 Multiviewer Switcher

Its a fully new multifunctional video processor, which comes with 3 functions. It’s not only a 4K Seamless 9×9 HDMI Matrix, but also a 3×3 video wall controller / 9×1 multi-viewer. It’s with 9 seamless switching outputs and 9 mixed inputs, with 1 HDMI loop out. Any one of 9 input sources can be displayed to any one of 9 outputs.

This processor is loaded with over 20 presets out of the box.There is no programming necessory! Just up to 9 HDMI inputs to your media sources and up to 9 HDMI outputs to your TVs and you will be up and running within minutes! Switching from screen to scene takes a matter of seconds.

4k 9x9 seamless hdmi matrix 3x3 video wall processor multiviewer big screen display

This 9X9 Matrix with 3×3 video wall processor is extremely unique because it supports multiple inputs and 4K resolution. Most of other processor that you find at online shop only support 1080P or only one input. You will get DOUBLE resolution with this processor, which makes a huge difference with 4K movies and presentations on you PC.

Installation is VERY easy and no programming. No need technical experience to operate this processor, and we are available at 24/7  to walk you through any issues that might arise.

4k 9x9 seamless hdmi matrix 3x3 video wall processor multiviewer big screen display

The Matrix offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and projector factory, noise, space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.

Features

1. 9xHDMI input; 9xHDMI output max resolution up to HDMI 1.4v 4K30Hz
2. Support video signal seamless switching; Video wall; Multi-Viewer; Preset setting, etc
3. Support Balanced Audio Extraction
4. Support Panel Button, IR, TCP/IP control, RS232 Commands control
5. With Built-in EDID (4K30Hz, 1080P, 4K60hz Beta, User)
6. HDCP 2.2/1.4 compliant
7. Support Micro USB for firmware updating
8. Video wall mode (Max 3×3) support adjust the screen edge

4k 9x9 seamless hdmi matrix 3x3 video wall processor multiviewer big screen display

Specificaiton:

Operating temperature range -5 to +40°C (23 to +104 °F)
Storage temperature range -10 to +60°C (-14 to +140 °F)
Operating humidity range 5 to 90% RH (no condensation)
Input port 9 x HDMI (standard type A connector)
Output port 9 x HDMI (standard type A connector)
Audio output Analog (balanced audio)
Supported video format 4K@30Hz/1080P/1080i/720P/576P/480P/576i/480i
Supported audio format PCM, DTS-5.1/7.1, Dolby-5.1/7.1 digital audio
HDCP compliant HDCP 2.2/1.4
Control way panel button, IR remote, TCP/IP, RS232
Matrix mode 9 x 9 seamless switching
Video wall mode multiple video wall modes
Multi-viewer mode multiple multi-viewer modes
USB port for firmware update
Unit size (LxWxH) 482.6×273.7x44m (1U rack design)
Weight 4KGS

4k 9x9 seamless hdmi matrix 3x3 video wall processor multiviewer big screen display
